Applications
Ideal for hazard marking, aquaculture, navigation, perimeter lighting & a host of other applications.
Main functions and features
• Based on LED technology, and its color complies to IALA Recommendations E-200-1.
• Integrated design, enabling a rugged and completely waterproof seal capable of prolonged and deep immersion (IP68).
• PC housing，UV resistance, shockproof and corrosion proof. Housing adapts the circumference focus Fresnel Lense. The case is made of stainless steel 316.
• With birds pike.
• 256 kinds of flashing rate are available, comply with IALA.
• Intensity can be adjusted from 25%, 50%, 75% and 100% of total intensity.
• With photocell, and manual switch.
• With Steel wire to prevent falling during mounting and adjusting.
• With built in sealed lead acid battery, easy for replace.
• No RF-radiations, EMC Compliant.
• Extremely Reliable and cost saving.
Specifications
Light Characteristics
Intensity >40cd
Visible Range >4nm
LED Available colors Red, amber, green, blue, white
Vertical degree >7°
Horizontal degree 360 °
Light source High Power LED
LED life ≥100,000 hr
Electrical Characteristics
Autonomy >20 days（12hour darkness，12.5%duty cycle）
On/off level 300 lux±100lux
Flashing rate complies to IALA Recommendations, total 256 available flashing rate( steady burning，adjustable )
Power Supply
Solar module type Monocrystalline silicon solar panel
Output 6W*4
Battery type No maintenance sealed lead acid battery
Battery capacity 12V/24 AH
Physical Characteristics
Integrated housing UV resistance PC, stainless steel 316 case
Waterproof IP68
Weight 20 KG
Ambient temperature -35℃ ~ +70℃
Size H:580mm, D:270mm
Mounting dimension Base:230mm .200mm Noda distribute 4*M16 holes
Customized External power or Infrared control
