LED SOLAR TRAFFIC SPEED LIMIT SIGN

LED SOLAR TRAFFIC SPEED LIMIT SIGN

LED Solar Traffic Speed Limit Signs are powered by solar energy and thus more environmentally-friendly. The control system for transforming light into electricity is extremely effective.

Applications:

Used for warning road users at crossings or dangerous areas where wiring not easy source. Adopting Solar power can create environment friendly, specializes in designing optical system resulting in wide visual angle and well distribution of light. Convenient in installation, no wires to embedding underground.

Set Descending Direction

1 Item(s)

  1. TQ-SLS600*600-5A  LED Solar Traffic Speed Limit Sign

    LED Solar Traffic Speed Limit Sign (TQ-SLS600*600-5A)

    LED Solar Traffic Speed Limit Signs are powered by solar energy and thus more environmentally-friendly. The control system for transforming light into electricity is extremely effective.



    Light Source: Ф5mm Super Bright LED.

    Dimensions:   Ф 400mm/Ф300mm, various polygon.

    Display Colors:  Yellow, Red,  White.

    Life of Solar Panel:  10 years.

    Life of battery:   2 years.

    Working mode:  flashing all the day / flashing only at night.

    Flashing Frequency:  35+_ time/minute.

    Protection Grade:  IP65.

    Luminance  Intensity:  >4000 cd/㎡.

    LED Visual Angle:  30 °

    Material:   Polycarbonate (PC) or Aluminum.

    Reted Voltage:  DC12V.

    Light/dark Contrast:   1:5

    Power Consumption:  <3W(5W).

    Dimension:  600mm×600mm



    Applications:

    Used for warning road users at crossings or dangerous areas where wiring not easy source.  Adopting Solar power can create environment friendly, specializes in designing optical system resulting in wide visual angle and well distribution of light. Convenient in installation, no wires to embedding underground.



    Specifications:



    Specification



    Solar battery

    Capacity

    2.5W

    Manufacture

    Germany

    Normal working life

    10 years

    Accumulator

    Capacity

    4400MAH/11V

    Manufacture

    USA

    Normal working life

    Up to 3 years

    LED

    Producing area

    America

    Intensity of one LED

    4000 mcd

    Normal working life

    80,000 hours

    Working temperature

    -30 ~ 40℃

    Flashing Frequency

    1 HZ

    Work and vacancy proportion

    1 :3

    Luminance proportion at day and night

    2 :1

    Working time of continuous rainy day

    7 days

    Working voltage

    12 V

    Working current at day

    250 mA

    Visual distance

    >500 m
