  1. TQ-SRLM25 LED Solar Street Lights 30W

    Characteristics:

    • Powered by Solar energy, no need to pave cable
    • Our products come with the latest, most advanced and quality assured LED Technology that combine stylish looks and safety.
    • Green, Environment friendly, low carbon and energy saving
    • Original German solar controller adopted
    • Class A solar panel used, converting efficiency > 16%
    • Time-phase power deduction control available, further optimize cost Main Technology Index:

    Main Technology Index:

    Model No.

    TQ-SRLM25 LED Solar Street Lights (USA and Germany Technology)  30W

    Total power consumption

    30W

    Replacement

    90W - 150W for High Pressure Sodium Lamp

    Daily working hours

    12 hrs

    Peak sunshine duration

    4.5 hrs

    Continuously rainy days

    4 days

    Interval between rainy days

    20 days

    Solar panel

    120W/17.5V 1PC

    Battery

    120AH/12V 1PC

    Solar controller

    10A/12V

    Learn More
  2. TQ-S120  LED High Power Solar Street Light 120W  (USA Technology)

    Technical Specifications:

    Model No.:

    TQ-SL120  LED High Power Solar Street Light 120W  (USA Technology)

    Solar Panel: (pcs)

    2 x 170Wp 35.5V, high-efficiency mono or polycrystalline PV  module, A-class

    LED Light Source:

    LED Power: 120W  DC24V; LED Street Lamp, Bridgelux  50MIL LED Chips, 110~120LM/W

    Replacement Traditional Lamp HPSV

    300W HPSV Lamp

    Controller:

    24V 15A, light/time intelligent control, PWM mode;  various protections; Waterproof, IP66 guard level; various protections

    Battery:

    2 pcs x 12V 180AH, solar special lead-acid battery, fully sealed deep cycle free maintenance type

    Pole Set:

    Come with 10m high, Q235 steel pipe; hot-dip galvanized and spray coated treatment, rustproof; including solar panel bracket, lamp arm and foundation cage are included

    Battery Box:

    PVC material, underground-buried type, waterproof and heat-dissipative; including PVC cable tube

    Working Time: (hrs)

    10 hours/day (5 hours full power + 5 hours half power lighting), battery capacity providing 3 continuous days backup in cloudy or rainy condition
    Certifications CE and RoHS
    Learn More
  3. TQ-S100  LED High Power Solar Street Light 100W  (USA Technology)

    Technical Specifications:

    Model No.:

    TQ-SL100  LED High Power Solar Street Light 100W  (USA Technology)

    Solar Panel: (pcs)

    2 x 150Wp 35.5V, high-efficiency mono or polycrystalline PV  module, A-class

    LED Light Source:

    LED Power: 100W  DC24V; LED Street Lamp, Bridgelux  50MIL LED Chips, 110~120LM/W

    Replacement Traditional Lamp HPSV

    300W HPSV Lamp

    Controller:

    24V 15A, light/time intelligent control, PWM mode;  various protections; Waterproof, IP66 guard level; various protections

    Battery:

    2 pcs x 12V 150AH, solar special lead-acid battery, fully sealed deep cycle free maintenance type

    Pole Set:

    Come with 9m high, Q235 steel pipe; hot-dip galvanized and spray coated treatment, rustproof; including solar panel bracket, lamp arm and foundation cage are included

    Battery Box:

    PVC material, underground-buried type, waterproof and heat-dissipative; including PVC cable tube

    Working Time: (hrs)

    10 hours/day (5 hours full power + 5 hours half power lighting), battery capacity providing 3 continuous days backup in cloudy or rainy condition
    Certifications CE and RoHS
    Learn More
  4. TQ-S80  LED High Power Solar Street Light 80W  (USA Technology)

    Technical Comments:
    (a)  Above system configurations are based on scientific calculation and engineering project experience. They are suitable for areas with annual average peak power sunshine of 4.5hrs per day. Battery capacity is designed for 3 days backup in cloudy or rainy weather.
    (b)  The system configurations can be customized based on client's specific project requirement and weather conditions.
    (c)  The batteries are suggested to be placed in battery box and buried in a underground cement pit. In this way, it can avoid overhigh temperature due to sunshine exposure or too cold weather in Winter, Waterproof and Theftproof, easy for replacement for post sales supports.
    (d)  The pole patterns are standardized type, practical and economical, which can also be customized as per client's specific requirement.
    (e)  All parts are certified by CE and ROHS certificates, compliances to USA and European standard.


    Technical Specifications:

    Model No.:

    TQ-SL80  LED High Power Solar Street Light 80W  (USA Technology)

    Solar Panel: (pcs)

    2 x 130Wp 17.5V, high-efficiency mono or polycrystalline PV  module, A-class

    LED Light Source:

    LED Power:  80W  DC24V; LED Street Lamp, Bridgelux  50MIL LED Chips, 110~120LM/W

    Replacement Traditional Lamp HPSV

    260W HPSV Lamp

    Controller:

    24V 10A, light/time intelligent control, PWM mode;  various protections; Waterproof, IP66 guard level; various protections

    Battery:

    2 pcs x 12V 120AH, solar special lead-acid battery, fully sealed deep cycle free maintenance type

    Pole Set:

    Come with 8m high, Q235 steel pipe; hot-dip galvanized and spray coated treatment, rustproof; including solar panel bracket, lamp arm and foundation cage are included

    Battery Box:

    PVC material, underground-buried type, waterproof and heat-dissipative; including PVC cable tube

    Working Time: (hrs)

    10 hours/day (5 hours full power + 5 hours half power lighting), battery capacity providing 3 continuous days backup in cloudy or rainy condition
    Certifications CE and RoHS
    Learn More
  5. TQ-S70  LED High Power Solar Street Light 70W  (USA Technology)

    Technical Comments:
    (a)  Above system configurations are based on scientific calculation and engineering project experience. They are suitable for areas with annual average peak power sunshine of 4.5hrs per day. Battery capacity is designed for 3 days backup in cloudy or rainy weather.
    (b)  The system configurations can be customized based on client's specific project requirement and weather conditions.
    (c)  The batteries are suggested to be placed in battery box and buried in a underground cement pit. In this way, it can avoid extremely high temperature due to sunshine exposure or too cold weather in Winter, Waterproof and Theftproof, easy for replacement for post sales supports.
    (d)  The pole patterns are standardized type, practical and economical, which can also be customized as per client's specific requirement.
    (e)  All parts are certified by CE and ROHS certificates, compliances to USA and European standard.


    Technical Specifications:

    Model No.:

    TQ-SL70  LED High Power Solar Street Light 70W  (USA Technology)

    Solar Panel: (pcs)

    2 x 130Wp 17.5V, high-efficiency mono or polycrystalline PV  module, A-class

    LED Light Source:

    LED Power:  70W  DC24V; LED Street Lamp, Bridgelux  50MIL LED Chips, 110~120LM/W

    Replacement Traditional Lamp HPSV

    260W HPSV Lamp

    Controller:

    24V 10A, light/time intelligent control, PWM mode;  various protections; Waterproof, IP66 guard level; various protections

    Battery:

    2 pcs x 12V 120AH, solar special lead-acid battery, fully sealed deep cycle free maintenance type

    Pole Set:

    Come with 8m high, Q235 steel pipe; hot-dip galvanized and spray coated treatment, rustproof; including solar panel bracket, lamp arm and foundation cage are included

    Battery Box:

    PVC material, underground-buried type, waterproof and heat-dissipative; including PVC cable tube

    Working Time: (hrs)

    10-12 hours/day (10 hours full power lighting or 6 hours full power +6 hours half power lighting), battery capacity providing 3 continuous days backup in cloudy or rainy condition
    Certifications CE and RoHS
    Learn More
  6. TQ-SL60  LED High Power Solar Street Light 60W  (USA Technology)

    Technical Specifications:

    Model No.:

    TQ-SL60  LED High Power Solar Street Light 60W  (USA Technology)

    Solar Panel: (pcs)

    2 x 110Wp 17.5V, high-efficiency mono or polycrystalline PV  module, A-class

    LED Light Source:

    LED Power:  60W  DC24V; LED Street Lamp, Bridgelux  50MIL LED Chips, 110~120LM/W

    Replacement Traditional Lamp HPSV

    220W HPSV Lamp

    Controller:

    24V 10A, light/time intelligent control, PWM mode;  various protections; Waterproof, IP66 guard level; various protections

    Battery:

    2 pcs x 12V 100AH, solar special lead-acid battery, fully sealed deep cycle free maintenance type

    Pole Set:

    Come with 8m high, Q235 steel pipe; hot-dip galvanized and spray coated treatment, rustproof; including solar panel bracket, lamp arm and foundation cage are included

    Battery Box:

    PVC material, underground-buried type, waterproof and heat-dissipative; including PVC cable tube

    Working Time: (hrs)

    10 hours/day (full power lighting), battery capacity providing 3 continuous days backup in cloudy or rainy condition
    Certifications CE and RoHS
    Learn More
  7. TQ-SL40  LED High Power Solar Street Light 40W  (USA Technology)

    Technical Specifications:

    Model No.:

    TQ-SL40  LED High Power Solar Street Light 40W  (USA Technology)

    Solar Panel: (pcs)

    2 x 80Wp 17.5V, high-efficiency mono or polycrystalline PV  module, A-class

    LED Light Source:

    LED Power:  40W  DC12V; LED Street Lamp, Bridgelux  50MIL LED Chips, 110~120LM/W

    Replacement Traditional Lamp HPSV

    110W HPSV Lamp

    Controller:

    12V 15A, light/time intelligent control, PWM mode;  various protections; Waterproof, IP66 guard level; various protections

    Battery:

    12V 150AH, solar special lead-acid battery, fully sealed deep cycle free maintenance type

    Pole Set:

    Come with 6m high, Q235 steel pipe; hot-dip galvanized and spray coated treatment, rustproof; including solar panel bracket, lamp arm and foundation cage are included

    Battery Box:

    PVC material, underground-buried type, waterproof and heat-dissipative; including PVC cable tube

    Working Time: (hrs)

    10 hours/day (full power lighting), battery capacity providing 3 continuous days backup in cloudy or rainy condition
    Certifications CE and RoHS
    Learn More
  8. TQ-SL30  LED Solar Street Light 30W  (USA Technology)

    Technical Specifications:

    Model No.:

    TQ-SL30  LED Solar Street Light 30W  (USA Technology)

    Solar Panel: (pcs)

    110Wp 17.5V, high-efficiency mono or polycrystalline PV  module, A-class

    LED Light Source:

    LED Power:  30W  DC12V; LED Street Lamp, Bridgelux  50MIL LED Chips, 110~120LM/W

    Replacement Traditional Lamp HPSV

    110W HPSV Lamp

    Controller:

    12V 10A, light/time intelligent control, PWM mode;  various protections; Waterproof, IP66 guard level; various protections

    Battery:

    12V 100AH, solar special lead-acid battery, fully sealed deep cycle free maintenance type

    Pole Set:

    Come with 5m high, Q235 steel pipe; hot-dip galvanized and spray coated treatment, rustproof; including solar panel bracket, lamp arm and foundation cage are included

    Battery Box:

    PVC material, underground-buried type, waterproof and heat-dissipative; including PVC cable tube

    Working Time: (hrs)

    10 hours/day (full power lighting), battery capacity providing 3 continuous days backup in cloudy or rainy condition
    Certifications CE and RoHS
    Learn More
  9. TQ-SRL72 LED Solar Street Light  72W



    Item No.

    TQ-SRL72 LED Outdoor Solar Street Lights (USA and Germany Technology)

    Outdoor LED Solar Street Light Source

    72 × 1W CREE LED

    LED Total Power

    72W (two heads,48W+24W)

    Replacement

    240W - 360W for High Pressure Sodium Lamp

    LED Initial Flux

    9000lm(Tj=25℃)

    Solar Panel

    17.5V/270W(Average daily sunlight:7hrs)

    Learn More
  10. TQ-SRL60 LED Solar Street Light  70W



    Item No.

    TQ-SRL60 LED Outdoor Solar Street Lights

    Total power consumption

    70W

    Solar panel

    70W/17.5V 4PCS

    Replacement

    180W - 300W for High Pressure Sodium Lamp

    Battery

    200AH/12V 2PCS

    Solar Street Light controller

    20A/24V

    Learn More
