LED High Power Street Light J Series - LED Super Bright Street Light, Flood Light, High Bay Light, Wall Washer Light and Solar Street Light

TQ-JRA1-MINI-S40 LED High Power Mini Street Light J Series 44W (USA Technology)

Technical Parameters

LED Power	44w
LED Light Source Types	CREE or BridgeLux USA or Osram Germany Chip Technology
LED Total Quantities	18pcs
IP Grade	IP65
Color Temperature	6500K / 4500K / 3000K
Input Voltage	AC 100-277v
Working Temperature	-25℃~50℃
Recommended Installation Height (m)	3-6m
Luminous Flux	3950lm /3650lm / 2960lm
Install Pipe Dimension (mm)	ø48mm
Lifespan	﹥50000Hs
Material	High strength die-casting aluminum alloy cover with electrostatic spray treatment. And also come with diffuser with 4.0mm super white toughened glass
Gross Weight	3Kg

Learn More

Technical Parameters

LED Power	230w
LED Light Source Types	CREE or BridgeLux USA or Osram Germany Chip Technology
LED Total Quantities	96pcs
IP Grade	IP67
Color Temperature	6500K / 4500K / 3000K
Input Voltage	AC 100-277v
Working Temperature	-25℃~50℃
Recommended Installation Height (m)	12-14m
Luminous Flux	25450lm / 23570lm / 19090lm
Install Pipe Dimension (mm)	ø60mm
Lifespan	﹥50000Hs
Material	IP67 modular design adopts ASTM6063 material, surface with black anodized treatment result in better heat radiation ability
Gross Weight	9.5Kg

Learn More

Technical Parameters

LED Power	200w
LED Light Source Types	CREE or BridgeLux USA or Osram Germany Chip Technology
LED Total Quantities	84pcs
IP Grade	IP67
Color Temperature	6500K / 4500K / 3000K
Input Voltage	AC 100-277v
Working Temperature	-25℃~50℃
Recommended Installation Height (m)	11-13m
Luminous Flux	22050lm / 20420lm / 16540lm
Install Pipe Dimension (mm)	ø60mm
Lifespan	﹥50000Hs
Material	IP67 modular design adopts ASTM6063 material, surface with black anodized treatment result in better heat radiation ability
Gross Weight	9.5Kg

Learn More

Technical Parameters

LED Power	180w
LED Light Source Types	CREE or BridgeLux USA or Osram Germany Chip Technology
LED Total Quantities	72pcs
IP Grade	IP67
Color Temperature	6500K / 4500K / 3000K
Input Voltage	AC 100-277v
Working Temperature	-25℃~50℃
Recommended Installation Height (m)	10-12m
Luminous Flux	19380lm / 17940lm / 14540lm
Install Pipe Dimension (mm)	ø60mm
Lifespan	﹥50000Hs
Material	IP67 modular design adopts ASTM6063 material, surface with black anodized treatment result in better heat radiation ability
Gross Weight	9.5Kg

Learn More

Technical Parameters

LED Power	150w
LED Light Source Types	CREE or BridgeLux USA or Osram Germany Chip Technology
LED Total Quantities	60pcs
IP Grade	IP67
Color Temperature	6500K / 4500K / 3000K
Input Voltage	AC 100-277v
Working Temperature	-25℃~50℃
Recommended Installation Height (m)	9-11m
Luminous Flux	16190lm / 14990lm / 12150lm
Install Pipe Dimension (mm)	ø60mm
Lifespan	﹥50000Hs
Material	IP67 modular design adopts ASTM6063 material, surface with black anodized treatment result in better heat radiation ability
Gross Weight	9.5Kg

Learn More

Technical Parameters

LED Power	120w
LED Light Source Types	CREE or BridgeLux USA or Osram Germany Chip Technology
LED Total Quantities	48pcs
IP Grade	IP67
Color Temperature	6500K / 4500K / 3000K
Input Voltage	AC 100-277v
Working Temperature	-25℃~50℃
Recommended Installation Height (m)	8-10m
Luminous Flux	12920lm / 11960lm / 9690lm
Install Pipe Dimension (mm)	ø60mm
Lifespan	﹥50000Hs
Material	IP67 modular design adopts ASTM6063 material, surface with black anodized treatment result in better heat radiation ability
Gross Weight	9.5Kg

Learn More

Technical Parameters

LED Power	93w
LED Light Source Types	CREE or BridgeLux USA or Osram Germany Chip Technology
LED Total Quantities	36pcs
IP Grade	IP67
Color Temperature	6500K / 4500K / 3000K
Input Voltage	AC 100-277v
Working Temperature	-25℃~50℃
Recommended Installation Height (m)	8-10m
Luminous Flux	10160lm / 9410lm / 7620lm
Install Pipe Dimension (mm)	ø60mm
Lifespan	﹥50000Hs
Material	IP67 modular design adopts ASTM6063 material, surface with black anodized treatment result in better heat radiation ability
Gross Weight	9Kg

Learn More

Technical Parameters

LED Power	60w
LED Light Source Types	CREE or BridgeLux USA or Osram Germany Chip Technology
LED Total Quantities	24pcs
IP Grade	IP67
Color Temperature	6500K / 4500K / 3000K
Input Voltage	AC 100-277v
Working Temperature	-25℃~50℃
Recommended Installation Height (m)	6-8m
Luminous Flux	6400lm / 5920lm / 4800lm
Install Pipe Dimension (mm)	ø60mm
Lifespan	﹥50000Hs
Material	IP67 modular design adopts ASTM6063 material, surface with black anodized treatment result in better heat radiation ability
Gross Weight	8Kg

Learn More

Technical Parameters

LED Power	150w
LED Light Source Types	CREE or BridgeLux USA or Osram Germany Chip Technology
LED Total Quantities	96pcs
IP Grade	IP65
Color Temperature	6500K / 4500K / 3000K
Input Voltage	AC 100-277v
Working Temperature	-25℃~50℃
Recommended Installation Height (m)	10-12m
Luminous Flux	16020lm / 14840lm / 12020lm
Install Pipe Dimension (mm)	ø60mm
Lifespan	﹥50000Hs
Material	High strength die-casting aluminum alloy cover with electrostatic spray treatment. And also come with diffuser with 4.0mm super white toughened glass
Gross Weight	12Kg

Learn More

Technical Parameters

LED Power	110w
LED Light Source Types	CREE or BridgeLux USA or Osram Germany Chip Technology
LED Total Quantities	64pcs
IP Grade	IP65
Color Temperature	6500K / 4500K / 3000K
Input Voltage	AC 100-277v
Working Temperature	-25℃~50℃
Recommended Installation Height (m)	8-10m
Luminous Flux	12220lm / 11320lm / 9170lm
Install Pipe Dimension (mm)	ø60mm
Lifespan	﹥50000Hs
Material	High strength die-casting aluminum alloy cover with electrostatic spray treatment. And also come with diffuser with 4.0mm super white toughened glass
Gross Weight	12Kg

Learn More
