Characteristics: TQ-SPG-120W LED High Bay Light
- Lightweight aluminium structure coated to withstand the elements, from extreme cold and heat to high humidity
- Our products come with the latest, most advanced and quality assured LED Technology that combine styling looks, maintenance free and safety.
- Start quickly, high light efficiency, clear eye-sight. No flicker. Operate safely. No damages to eyes and skin
- It can save 65 percent energy of the high voltage sodium lamp at the same intensity
- Easier to be installed and used
- High stability and low light pollution, LED has a high stability, and it is a real environmentally friendly and energy saving product
Main Technology Index: (USA Technology)
Product Name
|
LED High Bay Light (USA Technology)
|
Model No.
|
TQ-SH120
|
LED Light Source
|
CREE XP-E
|
Replacement
|
350W - 600W for Traditional Lamp Lights
|
LED Quantity
|
45 PCS
|
LED Luminous Efficiency
|
107-122lm/w
|
Lamp Total Power
|
120W
|
Power Efficiency
|
86%
|
Lamp Total Flux
|
8000 lm
|
lllumination and Effective Area
|
lllumination
|
Effective Area
|
Height 5M
|
61 lux
|
⊙ 8m Circle
|
Height 6M
|
53 lux
|
⊙ 9.5m Circle
|
Height 7M
|
40 lux
|
⊙ 11m Circle
|
Height 8M
|
29 lux
|
⊙ 12.5m Circle
|
Color Rendering Index(CRI)
|
Ra≥ 75
|
Color Temperature(CCT)
|
2700 - 3500K;
4000 - 5000K;
5000 - 6300K
|
Beam Angle
|
80 degrees
|
Light Distribution/Beam Pattern
|
Round Beam
|
Input Voltage
|
100-240 V AC
|
Frequency
|
47-63Hz
|
Power Factor(PF)
|
≥ 0.95
|
Total Harmonic Distortion(THD)
|
≤ 15%
|
Storage Temperature
|
－40℃--+80℃
|
Working Environment
|
－40℃--+50℃; 10%-90%RH
|
Working Lifetime
|
> 50,000 hours
|
IP Rating
|
IP44
|
Lamp Body Material
|
Aluminum 6063
|
Net Weight
|
4.7kg
|
Gross Weight
|
7.0kg
|
Product Dimension(mm)
|
￠319 x H392 mm
|
Package Size(mm)
|
L466 x W412 x H420 mm
|
