Pixel Pitch |
12mm |
Pixel configuration
|
1R1G1B
|
Density |
6,944 dot/m2 |
Display brightness |
5,000cd/m2 |
Display refresh rate |
>500Hz |
Viewing angle |
140 (+70/-70 degrees), (left and right viewing angle) |
Gray scale |
4,096 levels per color |
Digital processing |
10 bits |
Input voltage |
110 to 240V AC |
Ingress protection (front/rear) |
IP65 |
Frequency |
60Hz |
Screen body power consumption |
Maximum: 1,000W/m2 |
Average |
400W/m2 |
MTBF |
greater than 10,000 hours |
Working temperature |
-20 to +50°C |
Working humidity |
10 to 90% RH |
Blind spot rate |
<0.0001 |
Panel input format (with video processor) |
VGA, DVI, RGBHV, PbPr (HDTV) , composite, S-Video, TV |
Data interconnection |
super CAT5 cable
|
Operating systems |
Microsoft Windows XP, 2000 and more |
Install mode |
wall mount, hung, and stand structure |
Connecting Series |
VGA/NTSC/PAL |
