TQ-SG-70P LED Plant Grow Lights

More Views

LED Plant Grow Lights only delivers the spectrum of light used by plants for efficient and healthy growth. By leaving out the wavelengths plants won't use, they provide better energy efficiency than conventional grow lights. Over 80% of the light emitted from an HID Light is wasted in the form of non-absorbable light waves as well as heat energy.

The red and blue lights of LED will play an important role. A combination of both red and blue light would be required for the full growth of a fruit or flower bearing plant. It helps the plant in the process of photosynthesis. You can expect quick flowering, seeding, and fruits by our LED Plant Grow Light.



Red LED Light
- Plants will first absorb red light for the purpose of photosynthesis. Red light helps to flowing and bears fruit, it also help to prolong the flowering period.



Blue LED Light
- LED Plant Grow Light with blue color is useful for vegetable growth. After absorbing red light, the plant will absorb blue light and this light is responsible for the health of a plant. Moreover, the blue and green lights have more sunlight energy that is required for the healthy growth of vegetables.



  • Use high power Cree LED, provide different wavelength of light which can be fully absorbed by the plants

  • Enhancing plant growth, budding, flowering, plants photosynthesis

  • More than 80% energy saving

  • Easier installation and used

  • No ballasts or reflectors

  • Lead free, without mercury and other harmful substances, no filaments

  • No thermal radiation, No strobe light, No ultraviolet ray

LED Plant Grow Lights only delivers the spectrum of light used by plants for efficient and healthy growth. By leaving out the wavelengths plants won't use, they provide better energy efficiency than conventional grow lights. Over 80% of the light emitted from an HID Light is wasted in the form of non-absorbable light waves as well as heat energy.

The red and blue lights of LED will play an important role. A combination of both red and blue light would be required for the full growth of a fruit or flower bearing plant. It helps the plant in the process of photosynthesis. You can expect quick flowering, seeding, and fruits by our LED Plant Grow Light.



Red LED Light
- Plants will first absorb red light for the purpose of photosynthesis. Red light helps to flowing and bears fruit, it also help to prolong the flowering period.



Blue LED Light
- LED Plant Grow Light with blue color is useful for vegetable growth. After absorbing red light, the plant will absorb blue light and this light is responsible for the health of a plant. Moreover, the blue and green lights have more sunlight energy that is required for the healthy growth of vegetables.



  • Use high power Cree LED, provide different wavelength of light which can be fully absorbed by the plants

  • Enhancing plant growth, budding, flowering, plants photosynthesis

  • More than 80% energy saving

  • Easier installation and used

  • No ballasts or reflectors

  • Lead free, without mercury and other harmful substances, no filaments

  • No thermal radiation, No strobe light, No ultraviolet ray




Specifications:



































































































































Product Name



LED Plant Grow Light



Model No.



TQ-SG-70P (USA Technology)



LED Light Source



CREE LED (Blue + Red)



LED Quantity



70 PCS



Replacement



200W – 350W Metal Halide or High Pressure Sodium Lamp



LED Luminous Efficiency



30-50 lm/W



LED Initial Flux



3000 lm



Lamp Rated Total Power



65W



Power Efficiency



> 85%



Lamp Rated Total Luminous Flux



2250 lm (Tj=60℃,Ta=25℃)



lllumination and Effective Area



lllumination



Effective Area



Height 5M



50 lux



13m x10.5m



Height 6M



38 lux



15m x 12.5m



Height 7M



30 lux



17.5m x 14.5m



Height 8M



18 lux



20m x 16.5m



Beam Angle



Horizontal Axis: 100°; Vertical Axis: 90°



Light Distribution/Beam Pattern



Asymmetric/ Rectangular Beam



Input Voltage



AC 85 - 264V/277V



Frequency



47 - 63Hz



Power Factor(PF)



≥ 0.95



Total Harmonic Distortion(THD)



< 20%



Storage Temperature



-40℃- - +80℃



Working Environment



-40℃- - +50℃; 10% - 95% RH



Working Lifetime



> 50,000 hours



IP Rating



IP65



Lamp Body Material



Aluminum Alloy and Toughened Glass



Net Weight



11.6kg



Gross Weight



13.2kg



Product Dimension(mm)



488(L) x 331(W) x 224(H)



Package Size(mm)



540(L) x 385(W) x 250(H) (1 PC)
