Model No.
|
TQ-SC85 (USA Technology) 85W
|
LED Spec
|
CREE 1W
|
LED Quantity
|
60 pcs
|
Replacement
|
300W – 450W High Pressure Sodium Lamp HPSV
|
Certifications
|
UL, CE, RoHS, CE (EMC), CE (LVD) |
Working Current
|
400mA
|
LED Luminous efficacy
|
100 - 122lm @350mA
|
Input Voltage
|
90~305VAC
|
Power
|
85W
|
Luminous Flux
|
> 6400 LM
|
Luminous Efficacy
|
75lm/W
|
Bean Angle
|
130° * 60°
|
Power Factor
|
≥ 0.95
|
IP Rating
|
IP66
|
Power Supply Efficacy
|
90%
|
Color Temperature
|
Warm white: 2700-3500K Cool white: 4000-5000K Pure white: 5000-6300K
|
Color Rendering Index (CRI)
|
Ra >75
|
Frequency
|
47 ~ 63Hz
|
Total Harmonic Distortion (THD)
|
＜15%
|
Storage Temperature
|
-40℃ ~ +80℃
|
Working Temperature
|
-40℃~ + 50℃ 10% ~ 95% RH
|
Junction Temperature (Tj)
|
60℃ ± 10% (Ta +25℃)
|
Lamp Body Material
|
Die-casting Aluminum Alloy
|
Working Lifespan
|
＞ 50000hrs
|
Net Weight
|
12.8 Kg
|
Gross Weight
|
14.9 Kg
|
Product Size
|
865(L) x 335(W) x 109(H) mm
|
Packaging Size
|
937(L) x 396(W) x 170(H) mm
|
Average Illumination and Effective Area
|
6M Height
|
24m x 6m / 50 Lux
|
8M Height
|
34m x 8m / 28 Lux
|
10M Height
|
40m x 10m / 18 Lux
|
12M Height
|
50m x 12m / 12 Lux
|
